Dust-removing equipment

Classification

MF series pulse bag dust collector

Category: Dust-removing equipment

Introduction: Product IntroductionThe MF II square pulse bag filter is an improved and modified version of the MF I type.Performance characteristicsIt not only has the characteristics of high dust removal efficiency, large processing air volume, stable performance,…

+86-15861151117
Inquire

Product Introduction

The MF II square pulse bag filter is an improved and modified version of the MF I type.

Performance characteristics

It not only has the characteristics of high dust removal efficiency, large processing air volume, stable performance, and convenient operation and maintenance of Type I, but also has the advantages of better use effect, less powder accumulation, and wide application range compared to Type I.

Adapt to materials

Widely applicable for ventilation, dust removal, and dust recovery in industries such as grain and food, feed, metallurgy and chemical engineering, building materials, and pharmaceuticals.

Technical specifications


parameter model
MF48 MF60 MF72 MF84 MF96 MF108 MF120
filter area(m2) 36.2 45.2 54.3 63.3 72.4 81.4 90.5
Number of filter bags (piece) 48 60 72 84 96 108 120
Filtered air volume (m3/h) 6510-8680 8130-10840 9770-13000 11400-1520 13000-17370 14650-19530 16290-21700
Number of solenoid valves (piece) 8 10 12 14 16 18 20
Power (kW) 1.1 1.1 1.1 1.1 1.5 2.2 2.2
Filter bag specification (mm) 120×2000
Filtering wind speed (m/min) 3-4
Air leakage rate (%) ≤5
Injection pressure (Mpa) >0.4-0.6
Equipment resistance (Pa) <1200
Dust removal efficiency (%) ≥99.9(Select suitable filter media based on dust characteristics)


Technical specifications

parameter model
MF48 MF60 MF72 MF84 MF96 MF108 MF120
A 3530 3530 3530 3530 3530 3530 3530
B 3287 3287 3287 3287 3287 3287 3287
C 2552 2552 2552 2552 2552 2552 2552
D 1160 2260 1160 1160 1160 1160 1160
E 1350 1650 1950 2250 1350 2850 3150
F 1350 1350 1350 1350 1350 1350 1350
G 635 635 635 635 635 635 635
H 325 475 625 775 925 1075 1225
I 1586 1586 1586 1586 1586 1586 1586
J 790 790 790 790 850 850 850
K 824 824 824 824 824 824 824
M×N 400×500 500×500 600×500 700×600 700×600 800×600 800×600
P×Q 432×530 530×530 630×530 728×630 728×630 832×630 832×630
R×S 1050×1050 1350×1050 1650×1050 1950×1050 2250×1050 2250×1050 2850×1050
